RED Digital Cinema
KOMODO-X™
RED KOMODO-X® — Pure Cinema Power
Compact yet uncompromising, the RED KOMODO-X® delivers Super 35 global shutter performance in a rugged aluminum chassis. With REDCODE RAW and ProRes workflows, CFexpress media support, and onboard wireless control, it's engineered for cinema-grade creativity in a compact form.
Professional Cinema, Zero Compromise
At the heart of the KOMODO-X is a redesigned Super 35 global shutter sensor, offering up to 6K 80 fps, 4K 120 fps, and 2K 240 fps with 16.5 stops of dynamic range. With built-in Wi-Fi, USB-C Ethernet, and RED Control app compatibility, it’s ready for live broadcast, multicam setups, and IP workflows straight out of the box.
What’s in the Box
-
RED KOMODO-X® 6K Digital Cinema Camera (Body Only — Canon RF mount)
-
Integrated 2.9″ 1440×1440 Touchscreen LCD
-
Essential documentation
Highlights
-
Super 35 Global Shutter CMOS Sensor (19.9 MP)
-
Canon RF mount with full lens communication
-
Supports REDCODE RAW and Apple ProRes (422, 422 HQ, 422 LT, 4444, 4444XQ)
-
6K 80 fps / 5K 96 fps / 4K 120 fps / 2K 240 fps capture
-
CFexpress Type B slot (2.0)
-
12G-SDI, USB-C, audio, Genlock/Timecode I/O
-
Built-in Wi-Fi & USB-C Ethernet streaming
-
Compact and lightweight at 2.62 lb
Technical Specifications
| Specification | Details |
|---|---|
| SKU | 710-0356 |
| UPC | 810016943570 |
| Lens Mount | Canon RF with autofocus communication |
| Sensor | 27.03 × 14.26 mm Super 35 CMOS (19.9 MP) |
| Dynamic Range | 16.5 stops |
| Shutter | Electronic Global Shutter |
| Recording Formats | REDCODE RAW (HQ/MQ/LQ) & ProRes 422/4444/XQ |
| Frame Rates | 6K 80 fps / 5K 96 fps / 4K 120 fps / 2K 240 fps |
| Media Slot | 1× CFexpress Type B (2.0) |
| Outputs | 12G-SDI (BNC), USB-C, RED Monitor Out |
| Audio | Built-in mic & 5-pin LEMO input |
| I/O Interfaces | Genlock, Timecode, GPI via 9-pin EXT |
| Monitor | 2.9″ 1440×1440 Touchscreen LCD |
| Networking | Wi-Fi (2.4/5 GHz), USB-C Ethernet |
| Power | V-Mount (via optional mount) |
| Build | Aluminum |
| Dimensions | 5.09 × 3.99 × 3.75 in / 129 × 101 × 95 mm |
| Weight (Body) | 2.62 lb / 1.19 kg |
| Package Weight | Approx. 7.165 lb |
| Box Dimensions | 13.2 × 9.8 × 6 in |
